DJI Inspire 3 Drona 8K Open Box

DJI Inspire 3 Drona 8K

Caracteristici tehnice
Dimensiuni
-Dimensiuni travel mode:Inaltime: 176 mmLatime: 709.8 mmLungime: 500.5 mm
Greutate maxima de decolare
-2kg - 25kg
Distanta zbor
-peste 4000m
Tip drona
-Drone si minidrone
Numar elice
-4
GPS
-Da
Altitudine maxima
-3800 m (cu elice standard) /7000 m (cu elice High-Altitude)
Greutate (cu acumulator)
-Aproximativ 3.995 g (include camera gimbal, doua baterii, obiectivul, PROSSD si elicele)
Unghi maxim de inclinare
-N Mode: 35°S Mode: 40°A Mode: 35°T Mode: 20°Emergency Brake: 55°
Rezistenta maxima la vant
-Decolare/aterizare: 12 m/s; In zbor: 14 m/s
Viteza maxima (orizontal)
-94 Kph
Viteza maxima (urcare)
-8m/s
Viteza maxima (aterizare)
-Vertical: 8 m/s; Tilt: 10 m/s
Senzori coliziune
-Pozitionare senzori (corp drona)
Jos, Sus, Fata, Spate, Stanga, Dreapta
Raza de actiune senzori
-Fata-Spate: 1.5-48 m/Lateral: 1.5-42 m/Sus: 0.2-13 m/Jos: 0.3-18 m
Raza detectie obstacole
-Gama de masurare a senzorului infrarosu ToF 0-10 m
Unghi de cuprindere (spate)
-Orizontal 90°, Vertical 103°
Unghi de cuprindere (frontal)
Orizontal 90°, Vertical 103° (landing gear raised)/Orizontal 72°, Vertical 103° (landing gear lowered)
Mediu de operare (camp deschis)
Inainte, inapoi, la stanga, la dreapta si in sus: suprafete cu modele vizibile si iluminare adecvata (lux >15). Jos: suprafete cu modele perceptibile si reflectivitate difuza >20% (e.g., pereti, copaci, oameni); iluminare adecvata (lux >15) Detectarea obstacolelor este dezactivata in timp ce trenul de aterizare este in curs de ridicare sau coborare.
Telecomanda
Display integrat
Da
Frecventa operare
2.4 GHz, 5.8 GHz
Conectivitate
HDMI
Distanta maxima de operare telecomanda
Single Control Mode: FPV Camera: approx. 15 km (FCC), 8 km (CE/SRRC/MIC) Gimbal Camera (1080p/60fps live feeds): approx. 13 km (FCC), 7 km (CE/SRRC/MIC) Gimbal Camera (4K/30fps live feeds): approx. 5 km (FCC), 3 km (CE/SRRC/MIC) Dual-Control Mode: FPV Camera: approx. 12 km (FCC), 6.4 km (CE/SRRC/MIC) Gimbal Camera (1080p/60fps live feeds): approx. 11.2 km (FCC), 5.6 km (CE/SRRC/MIC) Gimbal Camera (4K/30fps live feeds): approx. 4 km (FCC), 2.4 km (CE/SRRC/MIC) Masurata intr-un mediu exterior fara obstacole si fara interferente, cu camera si obiectivul gimbal atasate la aeronava si fara alte accesorii. Datele de mai sus indica cea mai mare distanta de comunicare pentru zboruri dus-intors, fara intoarcere, in cadrul fiecarui standard. In timpul zborului, va rugam sa fiti atenti la memento-urile din aplicatie.
Acumulator telecomanda
Baterie incorporata: 3250mAh-7.2V (a set)/ Baterie externa: WB37 Intelligent Battery
Camera
Suport-inregistrare
DJI PROSSD 1TB
Rezolutie video
8K
Stabilizare de imagine
3 axe
Valoare ISO
FotoISO: 100-25600VideoEI: 200-6400
Camera integrata
Da
Format video
MOV, CinemaDNG
Format foto
JPG, DNG
Rezolutie
N/A
Gimbal
Numar axe
3
Raza de actiune gimbal
Mechanical RangeTilt: -128° to +110° (landing gear lowered)-148° to +90° (landing gear raised)Roll: -90° to +230°Pan: ±330°Controllable RangeTilt (landing gear lowered): Before gimbal pitch limit extension: -90° to +30°After gimbal pitch limit extension: -115° to +100°Tilt (landing gear raised): Before gimbal limit extension: -90° to +30°After gimbal limit extension: -140° to +75°Roll: ±20°Pan: ±300°
Alimentare si incarcare
Chimie acumulator
Li-Ion
Capacitate acumulator
4280 mAh
Putere maxima de incarcare
411 W
Putere intrare incarcator
100-240 V AC, max 8 A
Greutate acumulator
Aprox. 470 g
Autonomie
-
